Ultraminiature
Connectors suit limited space applications.
December
13, 2004 - Series SMCX connectors configure minimal
board-to-board height of 4.35 mm (BI) to 2.50 mm (BII). Surface
mount units deliver VSWR less than 1.2 and IR loss of -0.25 dB. They
are suited for applications operating up to 6 GHz, such as
UMTS/CDMA, 802.11 wireless/PCS devices, semiconductors, smartphones,
and M2M applications, and can be delivered in tray/reel
packaging.
Archive Press Release (Products mentioned in this Archive Press Release may or may
not be available from the manufacturer.)
Release
date: December 6, 2004
Ultraminiature Connectors Ideal for
Limited Space
The SMCX board to board (BI, BII) series is
a new range of ultraminiature connectors from Aliner Industries.
The connectors are ideal for use in space-limited
applications working up to 6GHz, such as UMTS/CDMA, 802.11
wireless/PCS devices, semiconductors, smartphones and M2M
applications.
Thanks to their miniature size, the SMCX series
offer the design engineers the benefits of board space savings
combined with superior RF characteristics for compact, high-density
electronic packages.
The new SMCX connectors configure a
minimal board-to-board height of 4.35mm (BI) to 2.50mm (BII),
providing a 43-67% of space saving to standard MCX series (7.58mm).
Other board heigh configurations as well as antenna connectors are
also avaible upon individual customer demands.
This new
series has been developed to replace two or three RF connectors with
a single board-to-board connection; therefore, BI and BII connectors
are ideal solutions where cost effectiveness and quick mounting
matter.
Available in surface mount, all of the connectors in
the series deliver VSWR less than 1.2, and IR loss of
-0.25dB.
To satisfy the demands of modern production
facilities, the SMCX series can be delivered in tray/reel packaging
for high volume pick and place manufacturing.
Following the
RF-connector trend of going smaller, higher frequency, and more cost
effective, Aliner's SMCX board-to-board series has been used in
various industrial applications in Japan and Taiwan.
Aliner's
board-to-board connectors are produced in compliance with RoHS
requirements.
Company Information: Name: Aliner Industries,
Inc. Address: No.32, Lane 387, Min An Road City:
Taipei ZIP: 242 Country: Taiwan Phone:
(011) 886-2-22055791 http://www.aliner.com.tw/
