The B4 Bevelling MahineBevelling Machine
Gravograph B4

Machine Characteristics
Machine: Ball Bearing Mounted tool.
Tool Speed: 14,000 r.p.m.
Motor: Universal 220 Volt
Weight: net 6,5 kg, gros 8 kg.

Accessories

  • Steel Cutter Ø 3.17 mm 45°
  • Steel Cutter Ø 3.17 mm 90°
  • Carbide Cutter Ø 3.17 mm 45°
  • Carbide Cutter Ø 3.17 mm 90°

The Gravograph B6 Bevelling MachineBevelling Machine
Gravograph B6

The B6 features Quality finish bevelling for quality items.

Total Safety: hands cannot come into contact with moving parts.

Swarf suction with anti-static box.

Special "rounded corner" bevelling.

Objects bevelled using the B6The B6 has a permissible plate depth of 8mm.
It also comes with an extra table for working large plates.

As well as these exceptional specifications the B6 also features a high-tec appearance and high speed operation.


The B6 is completely safeMachine Characteristics
Machine: Ball Bearing Mounted tool.
Tool Speed: 24,000 r.p.m.
Vertical Travel: 4 mm
Horizontal Travel: 15 mm
Vernier Scales: 2.5/100 mm
Carbon Cutter Diameter: 6.35 mm
Fastened by two opposed screws NOT by cutter knob.
Radius Device R: 5 - 10 - 15 mm
Table: 450 x 90 mm
Hold-down device for large plates.
Swarf suction and air filter
Total tool protection:
- removable top for access to cutter,
- transsparent hood over cutting edge.
Engraved plate thickness: up to 8 mm.
Max Depth of bevel at 45 degrees: 3.2 mm

Gravograph B6 - Standard Fittings
1 45° carbide cutter
1 90° carbide cutter
2 belts
3 radius devices (R = 5 - 10 - 15 )
Allen key
Instruction Leaflet.

Accessories
Extra table 1000 x 200 mm

Net Weight: 8.2 kg
