YOU ARE BIDDING ON THIS LARGE
DOMETIC THERMOSTABILIZER MODEL RCB42 P PORTABLE BLOOD
TRANSPORT REFRIGERATOR. IT MEASURES 32" X 22" X 20". THIS
EQUIPMENT IS PRISTINE AND GUARANTEED NOT D.O.A.!!!
PORTABLE, SOLID STATE, NO MOVING
PARTS, COOLING BY THERMOELECTRIC TECHNOLOGY,110/220 V, 50/60
HZ, AC AND 12-24-28 V DC; OLIVE DRAB,45 POUNDS; W/REMOVABLE
BASKET,TWO CARRYING HANDLES; AUDIBLE AND VISUAL ALARM SIGNAL
IS BOTH ELECTRICALLY AND BATTERY OPERATED; ACCOMMODATES
MINIMUM OF 30 WHOLE BLOOD UNITS OF 450 ML EACH OR 50 PACKED
RED BLOOD CELL UNITS OF 270 ML EACH; FOR STORAGE AND TRANSPORT
OF HUMAN BLOOD IN FIELD ENVIRONMENT
The RCB 42 P is a
thermostabilizer designed for storing and transporting
pre-cooled blood and medicinal products over long
periods of time. The refrigerating unit operates with
nearly all types of electricity (DC/AC). The RCB 42 P
ensures mobility and provides all the services of a
blood bank refrigerator. The RCB 42 P provides huge
storage capacity. It can contain up to thirty 500 ml
whole blood bags. It is standard-equipped with 2
plastic-laminated wire baskets that facilitate handling.
The forced-air refrigeration system ensures a constant,
even temperature. A thermoelectric unit (Peltier
block ) together with an electronic control unit keeps
the temperature in the cool box constant. The
thermoelectric unit is switched automatically from
cooling to heating , depending on the ambient
temperature. The perfect insulation ensures the
temperature in the cool box to be kept constant for up
to 10 hours when transporting or storing items without
power supply at an ambient temperature of +32 °C. The
temperature within the container can be thus maintained
at a preset temperature of +1 °C to +10 °C regardless of
external climatic conditions. This is even applicable at
ambient temperatures of 32 °C to +44 °C. The internal
temperature can be displayed by an optional temperature
recorder located in the container. Because of its
interference suppression the RCB 42 P is also operable
in airplanes. |
Cooling |
active |
Outside dimensions H x W x D
[mm] |
500 x 840 x
550 |
Inner dimensions H x W x D
[mm] |
240 x 495 x
335 |
Internal
compartment |
- |
Net weight [kg] |
29 |
Gross weight [kg] |
44 |
Internal gross volume
[L] |
43 |
Blood products storage capacity
[L] |
30 bags of 500
ml |
Cold life +32 °C
(hours) |
- |
Cold life +43 °C
(hours) |
- |
Shipping weight
[kg] |
36 |
Shipping volume
[m³] |
0,268 |
External material |
PE
(Polyethylene) |
Internal material |
PE
(Polyethylene) |
Insulation |
Polyurethane (CFC- and
HCFC-free) |
Insulation thickness
[mm] |
110 |
Accessories |
2 plastic laminated wire
baskets |
Accessories |
AC connection
cable |
Accessories |
DC connection
cable |
Accessories |
remote
alarm | | | | | |
MCRL
INFORMATION 4110-01-287-7111 |
Part No. |
RNCC |
RNVC |
RNFC |
SADC |
DAC |
CAGE |
Name |
DLA-50T |
5 |
1 |
|
|
4 |
0HAP0 |
THERMOPOL
IN |
M-30BT |
3 |
2 |
|
|
4 |
0HAP0 |
THERMOPOL
IN |
8-0593 |
3 |
1 |
|
|
4 |
64616 |
DEFENSE
MEDI |
RCB42P |
5 |
2 |
|
|
3 |
H4247 |
ELECTROLUX
H |
292.9903.15 |
5 |
1 |
4 |
|
1 |
H4247 |
ELECTROLUX
H |
ML-C
INFORMATION 4110-01-287-7111 |
SA |
SOS |
MCD |
UI |
QUP |
AAC |
SLC |
RC |
CIIC |
Price |
DS |
S9M |
------- |
EA |
1 |
V |
0 |
|
U |
10,273.70 |
DA |
S9M |
C2103N- |
EA |
1 |
V |
0 |
O |
U |
10,273.70 |
DF |
S9M |
------- |
EA |
1 |
V |
0 |
|
U |
10,273.70 |
DM |
S9M |
13M2--1 |
EA |
1 |
Y |
0 |
Z |
U |
10,195.60 |
DN |
S9M |
9L----- |
EA |
1 |
V |
0 |
|
U |
10,273.70 |
Procurement
History Information
4110-01-287-7111 |
Date |
Contract No. |
SOS |
Qty |
Price |
UI |
CAGE |
Vendor |
2001/04 |
SP020001WQ418 |
S9M |
1 |
7,100.00 |
EA |
0HAP0 |
THERMOPOL
IN |
Technical Characteristics ( ILs )
4110-01-287-7111 |
MRC |
Requirement |
Reply |
AYSX |
OUTSIDE SHELL
MATERIAL |
ANY
ACCEPTABLE |
BBDY |
CAPACITY AND
LOCATION |
1.0 CUBIC FEET MAXIMUM
REFRIGERATED STORAGE |
CXCY |
III PART NAME ASSIGNED BY
CONTROLLING AGENCY |
DLA-50T |
FEAT |
SPECIAL
FEATURES |
PORTABLE,SOLID STATE, NO
MOVING PARTS, COOLING BY THERMOELECTRIC
TECHNOLOGY,110/220 V, 50/60 HZ, AC AND 12-24-28 V DC;
OLIVE DRAB,45 POUNDS; W/REMOVABLE BASKET,TWO CARRYING
HANDLES; AUDIBLE AND VISUAL ALARM SIGNAL IS BOTH
ELECTRICALLY AND BATTERY |
FEAT |
~1 |
OPERATED; MAINTAINS
OPERATING TEMPERATURES BETWEEN 1-6 DEG C; ACCOMMODATES
MINIMUM OF 30 WHOLE BLOOD UNITS OF 450 ML EACH OR 50
PACKED RED BLOOD CELL UNITS OF 270 ML EACH; FOR STORAGE
AND TRANSPORT OF HUMAN BLOOD IN FIELD
ENVIRONMENT |
SUPP |
III SUPPLEMENTARY
FEATURES |
TO ORDER THE OPTIONAL
RECODER,TEMPERATURE,REFRIGERATOR, MODEL TR-3-5, USE NSN
6685-01-434-0712. |
"The sale of this
item may be subject to regulation by the U.S. Food and Drug
Administration and state and local regulatory agencies. If so,
do not bid on this item unless you are an authorized
purchaser. If the item is subject to FDA regulation, I will
verify your status as an authorized purchaser of this item
before shipping of the item."
