RB-35PW-OED3

-----------.

SPECIFICATIONS OF GEARED MOTOR

1 SCOPE

THE SPECIFICATIONS COVERS GEARED MOTORS RB-35PM-OED3 TO BE SUPPLIED

BY SAYAKA SEIIHTU KOGYO.

2 TYPE AND NAME

2-1 Geared motor

2-2 Motor

2-3 Gear head

2-4 Reduction ratio

:Type RB-35PM-OED3

:Type SK35-T06-U1

:Type RB-35P-OED3

:1/100

3 SPECIFICATIONS FOR APPEARANCE

3-1 External dimensions

3-2 Appearance

3-3 Output shaft Radial play

3-4 Output shaft Thrust play

:As per separate external drawings.

:No flaw or damage shall be observed.

:Max 0. 1 mm (A load of 113g perpendicular to the shaft
at a point 3mm from the end of the bearing)

:Yax 0. 35mm

4 ELECTRICAL PROPERTIES
These show characteristics at a room temperature and normal humidity,
but may vary according to the actual values obtainable at mass-production

4 - 1 Rated voltage

4 - 2 Rated allowable torque

4 - 3 Rated speed

4 - 4 Rated current

4 - 5 No load speed

4 - 6 No load current

4 - 7 Insulation resistance

4- 8 Dielectric strength

:DC12V

:3. 3kg • em

:52±8. 8rpm

:390mA MAX

:59± 8. 9rpm

:120mA MAX

:10 »Q or more shall be put through between the terminal
and the shaft at 250 VDC mega.
:No abnormality shall be observed after lOOVAC is
impressed for one minute between the terminal and the shaft.

is impressed on anode. ) /ISS _-

4- 9 Direction of revolution :CW, CCW (CW seen from the output shaft when t power

!!E_D

5 CONDITIONS

I N U S E (

5-1 Range of Temperature in use :-10 ·c- + 60 ·c SfPOZ. 1997 )

5-2 Range of storing temperature :-15 ·c - + 65 ·c ht=- · ""-4Q:/

5-3 Mounting posture :Output shaft horizontal direction £.aSID A;v-Y

6 SPECIFICATIONS FOR PACKING

Packing shall be done so that no damage may be done during transportation. , fjt

7 ADDITIONAL REMARKS

Any specification not given in this specifications shall be determined by
mutual consultation.

8 GREASE D-300
