1: Stepper Motor Driver
KL-8078 Price: $109.0 Heat Sink is included. Features: Specification 1: High
Performance
2:
Supply Voltage to +80VDC, 7.8A 3: Automatic Idle-Current
Reduction 4: Micro step Resolutions Up to 51,200 Steps/Rev. See
detail in specification 5: Optically Isolated Signal I/O 6: Inaudible
20KHz Chopping Frequency 7: TTL Compatible 8: 14 Selectable Resolutions in
Decimal & Binary 9: Mixed-Decay Current Control For Less Motor
Heating 10: Over-Current, Over-Voltage & Short-Circuit Protection 11:
Suitable for 4, 6, 8 wires motors 12: Size: L x W x H : 115 x 97 x
31mm One Year Warrenty
1.1 KL-8056 Bipolar Stepper Motor
Driver Heat Sink is included.:
Speification
SPECIFICATIONS: $92/pcs Supply
Voltage 20 up to 80 V DC Output Current 2.8 upto 5.6
A Step Modes 1/1, 1/2, 1/4, 1/8, 1/16, 1/32, 1/64 Suitable for 4, 6, 8
wires motors Current Adjustment via DIP Switches Clock Frequency 0 .. 400
kHz max. Pulse Width (Clock) min. 1.25 μs high/low Ambient Temperature 0°C
.. 50°C, Insure the driver temperature <65°C
FEATURES: -
Thermal protection - Short circuit and wrong polarity protection -
Optoisolated signal input
One Year Warrenty
2: KL- 5056
Microstepping Driver Heat Sink is included., $92/pcs Specification Features of this
driver * Supply voltage up to +50VDC, current output up to 5.6A peak *
Optically isolated input signals, pulse frequency up to 400 KHz *
Automatic idle-current
reduction * 3-state current
control for less motor heating *
16 selectable resolutions in
decimal and binary * Suitable
for 4,6,8 lead motors *
Stepping on upward or downward
pulse edge (selectable) * DIP
switch current setting with 8 different values *
Over-voltage and short-circuit
protection One Year Warrenty
3: KL- 5042 Microstepping Driver, Heat
Sink is included., $78/pcs Specification Features of this
driver
* Supply
voltage up to +50VDC, current output up to 4.2A peak * Optically
isolated input signals, pulse frequency up to 400 KHz *
Automatic idle-current
reduction * 3-state current control
for less motor heating * 16
selectable resolutions in decimal and binary *
Suitable for 4,6,8 lead
motors * Stepping on upward
or downward pulse edge (selectable) *
DIP switch current setting with
8 different values *
Over-voltage and short-circuit
protection One Year
Warrenty
3a: KL- 4030
Microstepping Driver, Heat Sink is included, $59.95 /pcs
Specification Features of this
driver * Voltage up to 24 to
40VDC, current output up to 3.0 A *
Selectable resolutions, 1,1/2,
1/4, 1/8, 1/16, 1/32, 1/64 *
Suitable for 4,6,8 lead
motors * DIP switch current
setting with different values *
Over voltage, heat and
short-circuit protection One Year Warrenty
4: KL-6050
Microstepping Driver, Heat Hink is included, $82.95 Specification Features of this
driver * Supply voltage up to 60VDC, current output up to 5.0 A peak *
Resolutions: 1/2,1/4,1/5, 1/8,1/10, 1/25, 1/32, 1/50, 1/64,
1/100, 1/128, 1/200, 1/256 * Over Voltage, Over Heat,
Over Current Protection * Suitable for 4,6,8 lead motors * DIP switch
current setting One Year Warrenty
5: Stepper Motor Driver KL-8082
(out of stock) Price: $129.0
Heat Sink is included. Features: 1: High Performance
2:
Supply Voltage to +80VDC, 8.2A 3: Automatic Idle-Current
Reduction 4: Micro step Resolutions Up to 51,200 Steps/Rev. See
detail in specification 5: Optically Isolated Signal I/O 6: Inaudible
20KHz Chopping Frequency 7: TTL Compatible 8: 14 Selectable Resolutions in
Decimal & Binary 9: Mixed-Decay Current Control For Less Motor
Heating 10: Over-Current, Over-Voltage & Short-Circuit Protection 11:
Suitable for 4, 6, 8 wires motors
One Year
Warrenty
6: KL-11078
Microstepping Driver, Heat Sink is included. : Specification Low heating for
motor & driver Supply voltage AC 80-220V TTL compatible
inputs Automatic idle-current reduction Output current up to 7.8A
peak Input frequency up to 400 kHz Opto-isolated inputs 16 selectable
microstep resolutions up to 10000 steps/rev Suitable for any 2-phase and
4-phase stepping motors DIP switch current setting Price: $199/pcs One
Year Warrenty Click for
